About this task
The following image indicates the location of the display back cover and provides a visual representation of the installation
procedure.
Figure 71. Installing the display back cover
Steps
Place the display back cover on a clean and flat surface.
Next steps
1. Install the eDP cable.
2. Install the camera.
3. Install the display panel.
4. Install the display bezel.
5. Install the display assembly.
6. Install the base cover.
7. Follow the procedure in After working inside your computer.
Removing and installing Field Replaceable Units (FRUs)
99
