Dell P2219HC - USB 2.0 Port Pin Assignments; USB 3.0 Port Pin Assignments

About Your Monitor | 25
USB 2.0 port USB 3.0port
Pin number Signal name
Pin number
Signal name
1 VCC 1 VBUS
2 DMD 2 D-
3 DPD 3 D+
4 GND 4 GND
5 StdA_SSRX-
6 StdA_SSRX+
7 GND_DRAIN
8 StdA_SSTX-
9 StdA_SSTX+
Shell Shield
