Dell P2223HC - DP Multi-Stream Transport (MST) Modes; Electrical Specifications

About your monitor  │  17
DP Multi-Stream Transport (MST) modes
MST Source Monitor Maximum number of external monitor that
can
be supported
1920 x 1080 @ 60 Hz
1920 x 1080 @ 60 Hz • 1 (via USB Type-C input)
• 3 (via DisplayPort input)
NOTE: Maximum external monitor resolution supported is 1920 x 1080
60 Hz only.
Electrical specifications
Model P2223HC
Video input signals • HDMI 1.4/DisplayPort 1.2*, 600 mV for each
diff
erential line, 100 ohm input impedance per
differential pair
• USB-C (with Alternate mode) signal input support
AC input voltage/
fr
equency/current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.5 A
(typical)
Inrush current • 120 V: 40 A (Max.) at 0°C (cold start)
• 240 V: 80 A (Max.) at 0°C (cold start)
Power consumption • 0.2 W (Off mode)
1
•0.3 W (Standby Mode)
1
• 12 W (On mode)
1
• 118 W (Max.)
2
•12.14 W (Pon)
3
•38.70 kWh (TEC)
3
*HBR2/DisplayPort 1.2 is supported.
1
As defined in EU 2019/2021 and EU 2019/2013.
2
Max brightness and contrast setting with maximum power loading on all USB
ports.
