10 | About Your Monitor
Monitor Specifications
Screen type Active matrix - TFT LCD
Panel Type In-plane switching Technology
Aspect ratio 16:9
Viewable image dimensions
Diagonal
60.47 cm (23.8 inches)
Active Area
Horizontal 527.04 mm (20.75 inches)
Vertical 296.46 mm (11.67 inches)
Area 156246.2 mm
2
(242.15 inches
2
)
Pixel pitch 0.2745 mm x 0.2745 mm
Pixel per inch (PPI) 93
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness 250 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Dynamic contrast ratio 8,000,000:1
Display screen coating Anti-glare treatment of the front polarizer (3H) hard
coating
Backlight White LED, EDGELIGHT system
Response Time 6 ms typical (G to G)
Color depth 16.7 million colors
Color gamut CIE 1976 (84%), CIE 1931 (72%)
NOTE: Color gamut is based on CIE 1976 (84%) and
CIE 1931 (72%) test standards.
Connectivity •1 x DP 1.2 (HDCP 1.4)
•1 x VGA
•1 x HDMI 1.4 (HDCP 1.4)
•2 x USB 2.0 downstream port
•1 x USB 3.0 downstream port
•1 x USB 3.0 with BC 1.2 charging capability at 2A (max)
•1 x USB 3.0 upstream port
•1 x Analog 2.0 audio line out (3.5 mm jack)
Border width (edge of monitor
to active area)
5.4 mm (Top)
5.4 mm (Left/Right)
19.51 mm (Bottom)
Adjustability
