8 | About Your Monitor
Back View
Label Description Use
1 VESA mounting holes (100 mm x
100 mm-behind attached VESA
cover)
Wall mount monitor using VESA-
compatible wall mount kit (100 mm x 100
mm).
2 Regulatory label Lists the regulatory approvals.
3 Security lock slot Secures monitor with security cable lock
(sold separately).
4 Stand release button Release stand from monitor.
5 Barcode, serial number, and Service
Tag label
Refer to this label if you need to contact
Dell for technical support.
6 Cable hook Use to route cables.
7 Cable routing label Shows how to route cables.
8 Cable management slot Use to organize cables by placing them
through the slot.
Side View
USB 3.0 downstream port
Port with battery icon supports BC 1.2.
