Setting Up the Monitor | 21
Setting Up the Monitor
Routing the Cables
CAUTION: Place monitor on a flat, clean, and soft surface to avoid scratching the
display panel.
• Remove the monitor protective cover and place the monitor with its front facing
downward on it.
• To routing the cables:
1. Insert DP cable into DP connector (see Connecting Your Monitor), press the
long side of cable hook and push cable to it from top to down.
2. Repeat step 1 to insert VGA/USB cables into corresponding connector and
organize the cables.
3. Finally, insert and organize the power cable and tighten all the cables as shown
above.
