Dell P2419HC User Manual

About Your Monitor | 11
Monitor Specifications
Model P2219HC P2419HC
Screen type Active matrix - TFT LCD
Panel Type In-Plane Switching Technology
Aspect ratio 16:9
Viewable image dimensions
Diagonal 546.10 mm (21.5 inches)
604.52 mm (23.8 inches)
Active Area
Horizontal 476.06 mm (18.74 inches) 527.04 mm (20.75 inches)
Vertical 267.79 mm (10.54 inches) 296.46 mm (11.67 inches)
Area 127484.10 mm²
(197.60 inches²)
156246.27 mm²
(242.18 inches²)
Pixel pitch 0.248 mm x 0.248 mm 0.275 mm x 0.275 mm
Pixel per inch (PPI) 102 92
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness 250 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
Faceplate coating Anti-Glare with 3H hardness
Backlight LED edgelight system
Response Time (Gray to Gray) 8 ms (NORMAL mode)
5 ms (FAST mode)
Color depth 16.7 million colors
Color gamut 72% (CIE1931)
NOTE: Color gamut (typical) is based on CIE1976
(82%) and CIE1931 (72%) test standards.
Connectivity •1 HDMI port
•1 DP(in) port
•1 DP(out) port
•1 USB Type-C port
•2 USB 2.0 downstream ports (rear)
•2 USB 3.0 downstream ports (side)
Border width (edge of monitor to
active area)
5.62 mm (Top/Left/
Right)
19.99 mm (Bottom)
5.38 mm (Top/Left/
Right)
20.31 mm (Bottom)
Adjustability

Dell P2419HC Specifications

General

3D	No
DDC/CI	Yes
Color gamut	72 %
Pixel pitch	0.275 x 0.275 mm
Aspect ratio	16:9
Screen shape	Flat
Pixel density	92 ppi
Response time	8 ms
Backlight type	LED
Display diagonal	24 \
Display technology	LCD
Vertical scan range	56 - 76 Hz
Maximum refresh rate	60 Hz
Response time (fast)	5 ms
Horizontal scan range	30 - 83 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal	604.52 mm
Viewable size, vertical	296.46 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527.04 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Certification	TCO
Product color	Black
Market positioning	Business
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 21 °
Height adjustment	130 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	119 W
Annual energy consumption	28 kWh
Power consumption (standby)	0.2 W
Power consumption (typical)	14.2 W
Power consumption (PowerSave)	16.73 W
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, USB Type-C
Package type	Box
Package depth	617.98 mm
Package width	165 mm
Package height	393.95 mm
Package weight	7300 g
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (side)	5.38 mm
Depth (with stand)	166 mm
Height (with stand)	356.11 mm
Weight (with stand)	5450 g
Bezel width (bottom)	20.31 mm
Depth (without stand)	42.8 mm
Width (without stand)	537.8 mm
Height (without stand)	322.15 mm
Weight (without stand)	3520 g
