6 | About Your Monitor
USB Type-C cable (C to C)
DP cable
Cable Tie
•Quick Setup Guide
•Safety,Environmental,and
Regulatory Information
Product Features
The Dell P2219HC/P2419HC/P2719HC monitor has an active matrix, thinfilm transistor
(TFT), liquid crystal display (LCD), and LED backlight. The monitor features include:
• P2219HC: 54.6cm (21.5-inch) viewable area display (measured diagonally).
1920x1080 resolution with full-screen support for lower resolutions.
• P2419HC: 60.5cm (23.8-inch) viewable area display (measured diagonally).
1920x1080 resolution with full-screen support for lower resolutions.
• P2719HC: 68.6cm (27.0-inch) viewable area display (measured diagonally).
1920x1080 resolution with full-screen support for lower resolutions.
• Color gamut of 72% NTSC.
• Tilt, swivel, height and rotate adjustment capabilities.
• Removable stand and Video Electronics Standards Association (VESA) 100 mm
mounting holes for flexible mounting solutions.
• Digital connectivity with DisplayPort and HDMI.
• Equipped with 4 USB downstream ports.
• Single USB Type-C to supply power to compatible notebook while receiving video
signal.
• Plug and play capable if supported by your system.
• Minimize eye discomfort with a flicker-free screen.
• The possible long-term effects of blue light emission from the monitor may cause
damage to the eyes, including eye fatigue or digital eye strain. ComfortView feature is
designed to reduce the amount of blue light emitted from the monitor to optimize eye
comfort.
• On-screen display (OSD) adjustments for easy setup and screen optimization.
• Security lock slot.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell P2419HC and is the answer not in the manual?

Dell P2419HC Specifications

General IconGeneral
3DNo
DDC/CIYes
Color gamut72 %
Pixel pitch0.275 x 0.275 mm
Aspect ratio16:9
Screen shapeFlat
Pixel density92 ppi
Response time8 ms
Backlight typeLED
Display diagonal24 \
Display technologyLCD
Vertical scan range56 - 76 Hz
Maximum refresh rate60 Hz
Response time (fast)5 ms
Horizontal scan range30 - 83 kHz
Supported video modes480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Viewable size diagonal604.52 mm
Viewable size, vertical296.46 mm
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewable size, horizontal527.04 mm
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
Ethernet LAN data rates10, 100, 1000 Mbit/s
CertificationTCO
Product colorBlack
Market positioningBusiness
USB hub version3.2 Gen 1 (3.1 Gen 1)
USB upstream port typeUSB Type-C
Number of upstream ports1
VGA (D-Sub) ports quantity0
USB Type-A downstream ports quantity4
Pivot angle-90 - 90 °
Tilt angle range-5 - 21 °
Height adjustment130 mm
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
Input current1.5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)119 W
Annual energy consumption28 kWh
Power consumption (standby)0.2 W
Power consumption (typical)14.2 W
Power consumption (PowerSave)16.73 W
Operating altitude0 - 5000 m
Non-operating altitude5000 - 12192 m
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, DisplayPort, USB Type-C
Package typeBox
Package depth617.98 mm
Package width165 mm
Package height393.95 mm
Package weight7300 g
Sustainability certificatesRoHS, EPEAT Gold, ENERGY STAR
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Bezel width (side)5.38 mm
Depth (with stand)166 mm
Height (with stand)356.11 mm
Weight (with stand)5450 g
Bezel width (bottom)20.31 mm
Depth (without stand)42.8 mm
Width (without stand)537.8 mm
Height (without stand)322.15 mm
Weight (without stand)3520 g
