Dell P2423D - Universal Serial Bus (USB) Interface

22 │ About your monitor
Universal Serial Bus (USB) interface
This section gives you information about the USB ports that are available on the
monitor.
SuperSpeed USB 5 Gbps (USB 3.2 Gen1)
Transfer speed Data rate
Maximum power supported
(each port)
SuperSpeed 5 Gbps 4.5 W
High speed 480 Mbps 4.5 W
Full speed 12 Mbps 4.5 W
USB 3.2 Gen1 upstream connector
Pin
number
9-pin side of the
connector
1 VCC
2 D-
3 D+
4 GND
5 SSTX-
6 SSTX+
7 GND
8 SSRX-
9 SSRX+
