Dell P2720D - Bottom View

12 │ About your monitor
Bottom view
7654
1
32
Bottom view without monitor stand
Label Description Use
1 Power connector Connect the power cable (shipped with your monitor).
2 Security-lock slot Secure your monitor using a security lock (purchased
separately) to prevent unauthorized movement of your
monitor.
3 Stand lock
feature
To lock the stand to the monitor using a M3 x 6 mm
screw (screw not included).
4 HDMI port Connect your computer with HDMI cable.
5 DisplayPort Connect your computer with DisplayPort cable
(shipped with your monitor).
6 USB 3.0
upstream port
Connect the USB cable from this port to your
computer to enable the USB ports on your monitor.
7 USB 2.0
downstream
ports x 2
Connect your USB device.
NOTE: To use this port, you must connect
the USB upstream cable (shipped with
your monitor) between the monitor and the
computer.
