12 │ About your monitor
Bottom view
Bottom view without monitor stand
Label Description Use
1 Security lock slot
(based on Kensington
Security Slot)
Secure your monitor using a security lock
(purchased separately) to prevent unauthorized
movement of your monitor.
2 Power connector Connect the power cable (shipped with your
monitor).
3 HDMI port Connect to your computer using a HDMI cable
(purchased separately).
4 Stand lock To lock the stand to the monitor using a M3 x 6
mm screw (screw not included).
5 DisplayPort (in) Connect your computer with the DisplayPort cable
(shipped with your monitor).
6 DisplayPort (out) DisplayPort output for MST (multi-stream
transport) capable monitor. To enable MST, see
Connecting the monitor for DP Multi-Stream
Transport (MST) function.
NOTE: Remove the rubber plug when
using DisplayPort out connector.
