Dell P2723QE User Manual

Operating your monitor │ 69
Adjusting the rotation display settings of your system
After you have rotated your monitor, you need to complete the procedure below to adjust
the Rotation Display Settings of your system.
NOTE: If you are using the monitor with a non-Dell computer, you need to go
to the graphics driver website or your computer manufacturer website for
information on rotating the 'contents' on your display.
To adjust the Rotation Display Settings:
1. Right-click on the desktop and click Properties.
2. Select the Settings tab and click Advanced.
3. If you have an ATI graphics card, select the Rotation tab and set the preferred
rotation.
4. If you have an NVIDIA graphics card, click the NVIDIA tab, in the left-hand
column select NVRotate, and then select the preferred rotation.
5. If you have an Intel
®
graphics card, select the Intel graphics tab, click Graphic
Properties, select the Rotation tab, and then set the preferred rotation.
NOTE: If you do not see the rotation option or it is not working correctly,
go to https://www.dell.com/support and download the latest driver for your
graphics card.

Dell P2723QE Specifications

General

Color gamut	99 %
Pixel pitch	0.1554 x 0.1554 mm
Screen shape	Flat
Pixel density	163 ppi
Backlight type	LED
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	24 - 86 Hz
Maximum refresh rate	60 Hz
Response time (fast)	8 ms
Horizontal scan range	15 - 135 kHz
Supported video modes	480p, 576p, 720p, 2160p
Viewable size diagonal	684.67 mm
Viewable size, vertical	335.66 mm
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	68.47 cm
Viewable size, horizontal	596.74 mm
Display brightness (typical)	350 cd/m²
Pivot angle	90 - 90 °
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-C
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Input current	2.5 A
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	169 W
Power consumption (standby)	0.2 W
Power consumption (typical)	26 W
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Doesn't contain	PVC/BFR
Sustainability certificates	ENERGY STAR, RoHS, TCO
Feet color	Silver
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Package weight	9680 g
Cables included	AC, DisplayPort, USB Type-A to USB Type-C, USB Type-C to USB Type-C
DisplayPort cable length	1.8 m
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	7.4 mm
Depth (with stand)	185 mm
Width (with stand)	611.6 mm
Height (with stand)	535.2 mm
Weight (with stand)	6870 g
Bezel width (bottom)	17.67 mm
Depth (without stand)	52.1 mm
Height (without stand)	360.7 mm
Weight (without stand)	5050 g
