About Your Monitor | 11
Bottom View
21 3 4
11
56 7 98 10
Label Description Use
1 Security lock slot Secures monitor with security cable lock
(sold separately).
2 AC power port To connect the monitor power cable.
3 HDMI port Connect your computer with HDMI cable (sold
separately).
4 DP port (in) Connect your computer with DP cable.
5 USB-C port Connect to your computer using the USB-C cable.
The USB-C port offer the fastest transfer rate and
the alternate mode with DP 1.4 support the maximum
resolution of 3840 x 2160 at 60 Hz PD 20 V / 3.25 A,
15 V / 3 A, 9 V / 3 A, 5 V / 3 A.
NOTE: USB-C is not supported on Windows versions
that are prior to Windows 10.
6&7
9&10
USB-A downstream
port (4)
Port with icon supports 5 V/ 0.9 A.
Connect your USB device. You can use these ports
only after you have connected the USB cable from
the computer to the monitor.
NOTE: To avoid signal interference, when a
wireless USB device has been connected to a USB
downstream port, it is NOT recommended to connect
any other USB devices to the adjacent port(s).
8 RJ-45 connector Connect Internet. You can surf Internet via RJ45 only
after you have connected the USB cable (A to C or
C to C) from the computer to the monitor.
11 Stand lock Lock the stand to the monitor using a M3 x 6 mm
screw (screw not included).
