About Your Monitor | 11
Bottom View
Label Description Use
1 Security lock slot Secures monitor with security cable lock
(sold separately).
2 AC power port To connect the monitor power cable.
3 HDMI port Connect your computer with HDMI cable (sold
separately).
4 DP port (in) Connect your computer with DP cable.
5
DP port (out) DP output for MST (multi-stream transport) capable
monitor. To enable MST, refer to instruction on
section “Connecting the Monitor for DP MST
Function”.
NOTE: Remove the rubber plug when using DP out
connector.
6 USB-C port Connect to your computer using the USB-C cable.
The USB-C port offer the fastest transfer rate and
the alternate mode with DP 1.4 support the maximum
resolution of 2560 x 1440 at 60 Hz PD 20 V / 4.5 A,
15 V / 3 A, 9 V / 3 A, 5 V / 3 A.
NOTE: USB-C is not supported on Windows versions
that are prior to Windows 10.
7&8
10&11
SuperSpeed USB 5
Gbps
（
USB 3.2 Gen 1
）
USB-A downstream
port (4)
Port with icon supports 5 V/ 0.9 A.
Connect your USB device. You can use these ports
only after you have connected the USB cable from
the computer to the monitor.
NOTE: To avoid signal interference, when a
wireless USB device has been connected to a USB
downstream port, it is NOT recommended to connect
any other USB devices to the adjacent port(s).
