Component Secured to Screw type Quantity Screw image

Wireless card System board M2x3 1

Display-cable

bracket

System board M2x3 2

Battery Palm-rest

assembly

M2x2 3

Battery Palm-rest

assembly

M1.6x4 1

Base cover Palm-rest

assembly

M2x3, Torx 8

Base cover Palm-rest

assembly

M1.6x6 1
