Replacing the base cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the screw holes on the base cover with the screw holes on the palm-rest
assembly and snap the base cover into place.
2 Using your ngertips, open the system badge.
3 Replace the screw (M1.6x4) under the system badge that secures the base
cover to the palm-rest assembly.
4 Replace the eight screws (M2x3, Torx) that secure the base cover to the palm-
rest assembly.
