Component Secured to Screw type Quantity Screw image
I/O board Palm-rest
assembly
M2x3 1
Fan System board M2x5 2
System board Palm-rest
assembly
M2x3 2
Touch-pad
bracket
Touch pad M2x3 6
Power-adapter
port
Palm-rest
assembly
M2x3 1
Display panel Display back-
cover and
antenna
assembly
M2x3 4
Display hinges Display back-
cover and
antenna
assembly
M2.5xM2.5 big
head
6
14
