Dell P63F - Page 52

2 Open the hinge to an angle of 90 degrees.
3 Open the latch and disconnect the power-button board cable from the system
board.
4 Remove the screw (M2x2) that secures the power-button board to the palm-
rest assembly.
5 Peel the tape that secures the power-button board to the palm-rest assembly.
6 Slide and remove the power-button board from the tab on the palm-rest
assembly.
52
