SECTION 7
ELECTRICAL PARTS LIST
• Items marked with a asterisk " * " are not
stocked since they are seldom required for
routine service. Some delay should be
anticipated when ordering these items.
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
RESISTORS
• All resistors are in ohms
• F : nonflammable
When indicating parts by reference
number, please include the board name.
The components identified by in this
manual have been carefully factory-
selected for each set in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
Note:
Note:
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
A
A
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
P780
— 37 —
* A-1294-798-A BOARD, COMPLETE
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C001 1-162-318-11 CERAMIC 0.001µF 10% 500V
C002 1-106-220-00 MYLAR 0.1µF 10% 100V
C004 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C007 1-104-664-11 ELECT 47µF 20% 25V
C008 1-104-664-11 ELECT 47µF 20% 25V
C009 1-126-925-11 ELECT 470µF 20% 10V
C010 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C011 1-106-220-00 MYLAR 0.1µF 10% 100V
C012 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C014 1-107-932-11 ELECT 47µF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C016 1-128-528-11 ELECT 470µF 20% 16V
C017 1-104-664-11 ELECT 47µF 20% 25V
C018 1-107-961-91 ELECT 10µF 20% 250V
C022 1-104-664-11 ELECT 47µF 20% 25V
C027 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C028 1-104-664-11 ELECT 47µF 20% 25V
C029 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C032 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C033 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C035 1-162-134-11 CERAMIC 470pF 10% 2KV
C036 1-104-503-12 CERAMIC CHIP 0.1µF 10% 100V
C042 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C044 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C046 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C047 1-104-664-11 ELECT 47µF 20% 25V
C049 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C050 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C053 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C054 1-137-528-11 FILM 0.1µF 10% 250V
C055 1-104-503-12 CERAMIC CHIP 0.1µF 10% 100V
C061 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C090 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C092 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C102 1-137-528-11 FILM 0.1µF 10% 250V
C104 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C105 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C106 1-137-528-11 FILM 0.1µF 10% 250V
C112 1-163-233-11 CERAMIC CHIP 18pF 5% 50V
C130 1-216-295-91 SHORT
C151 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C202 1-137-528-11 FILM 0.1µF 10% 250V
C204 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C205 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C206 1-137-528-11 FILM 0.1µF 10% 250V
C212 1-163-229-11 CERAMIC CHIP 12pF 5% 50V
C230 1-216-295-91 SHORT
C251 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C302 1-137-528-11 FILM 0.1µF 10% 250V
C304 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C305 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C306 1-137-528-11 FILM 0.1µF 10% 250V
C312 1-163-233-11 CERAMIC CHIP 18pF 5% 50V
C330 1-216-295-91 SHORT
C351 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
CONNECTOR
CN301 1-506-108-41 PIN, CONNECTOR (TERMINAL PIN)
CN303 1-695-915-11 TAB (CONTACT)
CN304 1-695-915-11 TAB (CONTACT)
CN305 * 1-564-512-11 PLUG, CONNECTOR 9P
CN306 * 1-564-509-11 PLUG, CONNECTOR 6P
CN309 * 1-564-511-11 PLUG, CONNECTOR 8P
CN310 * 1-779-944-21 PIN, CONNECTOR (PC BOARD) 4P
CN311 * 1-564-508-11 PLUG, CONNECTOR 5P
CN313 * 1-785-705-11 PIN, CONNECTOR (PC BOARD) 9P
DIODE
D001 8-719-970-02 DIODE 1SR139-400T31
D002 8-719-991-33 DIODE 1SS133T-77
D003 8-719-991-33 DIODE 1SS133T-77
D004 8-719-991-33 DIODE 1SS133T-77
D005 8-719-991-33 DIODE 1SS133T-77
