REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
P780
— 38 —
D007 8-719-109-89 DIODE RD5.6ESB2
D008 8-719-109-89 DIODE RD5.6ESB2
D014 8-719-991-33 DIODE 1SS133T-77
D015 8-719-991-33 DIODE 1SS133T-77
D104 8-719-970-83 DIODE HSS82
D105 8-719-970-83 DIODE HSS82
D106 8-719-970-83 DIODE HSS82
D111 8-719-062-51 DIODE 1PS226-115
D204 8-719-970-83 DIODE HSS82
D205 8-719-970-83 DIODE HSS82
D206 8-719-970-83 DIODE HSS82
D211 8-719-062-51 DIODE 1PS226-115
D304 8-719-970-83 DIODE HSS82
D305 8-719-970-83 DIODE HSS82
D306 8-719-970-83 DIODE HSS82
D311 8-719-062-51 DIODE 1PS226-115
FERRITE BEAD
FB001 1-412-911-11 FERRITE 0µH
FB004 1-412-911-11 FERRITE 0µH
FB005 1-412-911-11 FERRITE 0µH
FB006 1-412-911-11 FERRITE 0µH
FB008 1-535-143-61 LEAD, JUMPER (5.0MM)
FB009 1-412-911-11 FERRITE 0µH
FB010 1-412-911-11 FERRITE 0µH
FB011 1-412-911-11 FERRITE 0µH
FB012 1-412-911-11 FERRITE 0µH
FB102 1-216-295-91 SHORT
FB202 1-216-295-91 SHORT
FB302 1-216-295-91 SHORT
FILTER
FL002 1-412-911-11 FERRITE 0µH
IC
IC001 8-752-090-63 IC CXA2067S
IC002 8-759-593-11 IC LM2415
IC003 8-759-589-35 IC CXD9516P
IC004 8-749-016-27 IC H8D2957
IC005 8-759-100-96 IC UPC4558G2
IC006 8-759-269-07 IC SN74HCT02ANSR
JACK
J001
!
1-251-598-11 SOCKET, CRT
CHIP CONDUCTOR
JR002 1-216-296-91 SHORT
JR005 1-216-296-91 SHORT
JR006 1-216-296-91 SHORT
JR007 1-216-296-91 SHORT
JR016 1-216-296-91 SHORT
JR017 1-216-296-91 SHORT
JR018 1-216-295-91 SHORT
JR019 1-216-296-91 SHORT
JR020 1-216-296-91 SHORT
JR021 1-216-296-91 SHORT
COIL
L002 1-412-911-11 FERRITE 0µH
L003 1-408-397-00 INDUCTOR 1µH
L005 1-412-529-11 INDUCTOR 22µH
L007 1-410-482-31 INDUCTOR 100µH
LO09 1-216-295-91 SHORT
L010 1-412-911-11 FERRITE 0µH
L101 1-414-137-31 INDUCTOR 0.22µH
L102 1-412-052-21 INDUCTOR CHIP 1µH
L201 1-414-137-31 INDUCTOR 0.22µH
L301 1-414-137-31 INDUCTOR 0.22µH
TRANSISTOR
Q001 8-729-046-80 TRANSISTOR 2SC4634LS-CB11
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R002 1-216-043-91 RES, CHIP 560 5% 1/10W
R003 1-216-071-00 RES, CHIP 8.2K 5% 1/10W
R004 1-216-055-00 RES, CHIP 1.8K 5% 1/10W
R005 1-216-109-00 RES, CHIP 330K 5% 1/10W
R006 1-216-025-91 RES, CHIP 100 5% 1/10W
R007 1-216-025-91 RES, CHIP 100 5% 1/10W
R009 1-216-073-00 RES, CHIP 10K 5% 1/10W
R011 1-216-073-00 RES, CHIP 10K 5% 1/10W
R012 1-216-073-00 RES, CHIP 10K 5% 1/10W
R013 1-216-025-91 RES, CHIP 100 5% 1/10W
R014 1-216-025-91 RES, CHIP 100 5% 1/10W
R017 1-216-025-91 RES, CHIP 100 5% 1/10W
R018 1-216-025-91 RES, CHIP 100 5% 1/10W
R020 1-216-025-91 RES, CHIP 100 5% 1/10W
R021 1-216-025-91 RES, CHIP 100 5% 1/10W
R022 1-216-033-00 RES, CHIP 220 5% 1/10W
R023 1-216-049-91 RES, CHIP 1K 5% 1/10W
R024 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R028 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R029 1-216-099-00 RES, CHIP 120K 5% 1/10W
R030 1-216-025-91 RES, CHIP 100 5% 1/10W
R031 1-216-049-91 RES, CHIP 1K 5% 1/10W
R035 1-216-295-91 SHORT
R041 1-216-025-91 RES, CHIP 100 5% 1/10W
R045 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
