Dell P780 - 17" CRT Display User Manual

REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
P780
— 39 —
R046 1-216-097-91 RES, CHIP 100K 5% 1/10W
R047 1-216-073-00 RES, CHIP 10K 5% 1/10W
R048 1-219-398-51 METAL 2.2M 5% 1W
R049 1-216-697-91 METAL CHIP 82K 0.50% 1/10W
R051 1-216-049-91 RES, CHIP 1K 5% 1/10W
R052 1-216-073-00 RES, CHIP 10K 5% 1/10W
R053 1-219-621-91 METAL 22M 10% 1/4W
R062 1-216-295-91 SHORT
R064 1-202-830-00 SOLID 10K 20% 1/2W
R102 1-216-113-00 RES, CHIP 470K 5% 1/10W
R104 1-216-021-00 RES, CHIP 68 5% 1/10W
R106 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R107 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R108 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R109 1-216-113-00 RES, CHIP 470K 5% 1/10W
R111 1-249-409-11 CARBON 220 5% 1/4WF
R117 1-216-019-00 RES, CHIP 56 5% 1/10W
R118 1-216-009-91 RES, CHIP 22 5% 1/10W
R119 1-216-113-00 RES, CHIP 470K 5% 1/10W
R130 1-216-022-00 RES, CHIP 75 5% 1/10W
R151 1-202-549-00 SOLID 100 20% 1/2W
R161 1-215-394-00 METAL 75 1% 1/4W
R202 1-216-113-00 RES, CHIP 470K 5% 1/10W
R204 1-216-021-00 RES, CHIP 68 5% 1/10W
R206 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R207 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R208 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R209 1-216-113-00 RES, CHIP 470K 5% 1/10W
R211 1-249-409-11 CARBON 220 5% 1/4W F
R217 1-216-019-00 RES, CHIP 56 5% 1/10W
R218 1-216-009-91 RES, CHIP 22 5% 1/10W
R219 1-216-113-00 RES, CHIP 470K 5% 1/10W
R230 1-216-022-00 RES, CHIP 75 5% 1/10W
R251 1-202-549-00 SOLID 100 20% 1/2W
R261 1-215-394-00 METAL 75 1% 1/4W
R302 1-216-113-00 RES, CHIP 470K 5% 1/10W
R304 1-216-021-00 RES, CHIP 68 5% 1/10W
R306 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R307 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R308 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R309 1-216-113-00 RES, CHIP 470K 5% 1/10W
R311 1-249-409-11 CARBON 220 5% 1/4W F
R317 1-216-019-00 RES, CHIP 56 5% 1/10W
R318 1-216-009-91 RES, CHIP 22 5% 1/10W
R319 1-216-113-00 RES, CHIP 470K 5% 1/10W
R330 1-216-022-00 RES, CHIP 75 5% 1/10W
R351 1-202-549-00 SOLID 100 20% 1/2W
R361 1-215-394-00 METAL 75 1% 1/4W
SPARK GAP
SG001
!
1-519-422-11 GAP, SPARK
SG002
!
1-517-499-21 GAP, SPARK
SG101
!
1-517-499-21 GAP, SPARK
SG201
!
1-517-499-21 GAP, SPARK
SG301
!
1-517-499-21 GAP, SPARK
␣
A-1346-874-A D BOARD, COMPLETE
1-533-223-11 CLIP, FUSE
3-710-578-01 COVER, VOLUME, 6 MOLD
4-071-071-01 HOLDER, LED
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-11 SCREW (M3X10), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
CAPACITOR
C401 1-128-528-11 ELECT 470µF 20% 25V
C402 1-117-667-31 FILM 0.47µF 5% 250V
C403 1-107-911-11 ELECT 220µF 20% 50V
C404 1-128-528-11 ELECT 470µF 20% 25V
C405 1-104-760-11 CERAMIC CHIP 0.047µF 10% 50V
C406 1-137-368-11 FILM 0.0047µF 5% 50V
C407 1-137-372-11 FILM 0.022µF 5% 50V
C410 1-164-005-11 CERAMIC CHIP 0.47µF 25V
C501 1-126-964-11 ELECT 10µF 20% 50V
C502 1-137-370-11 FILM 0.01µF 5% 50V
C503 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C504 1-102-030-00 CERAMIC 330pF 10% 500V
C505 1-109-878-11 CERAMIC 15pF 5% 2KV
C506 1-126-960-11 ELECT 1µF 20% 50V
C507 1-131-653-11 FILM 0.19µF 5% 400V
C508 1-128-526-11 ELECT 100µF 20% 25V
C509 1-162-117-00 CERAMIC 100pF 10% 500V
C510 1-102-228-00 CERAMIC 470pF 10% 500V
C511 1-117-663-11 FILM 0.22µF 5% 250V
C512 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C513 1-107-906-11 ELECT 10µF 20% 50V
C514 1-115-521-11 FILM 0.82µF 5% 250V
C515 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C516 1-119-862-11 FILM 0.3µF 5% 250V
C517 1-137-370-11 FILM 0.01µF 5% 50V
C518 1-117-954-11 FILM 4300pF 3% 1.8KV
C519 1-117-621-11 FILM 1200pF 3% 1.2KV
C520 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C521 1-107-444-11 CERAMIC 100pF 5% 2KV
C522 1-136-684-51 MYLAR 0.0022µF 10% 100V
C523 1-117-660-21 FILM 0.12µF 5% 250V
C524 1-110-641-51 ELECT 33µF 20% 200V
C525 1-136-060-00 FILM 0.047µF 5% 400V
C526 1-164-646-11 CERAMIC 2200pF 10% 500V
C527 1-117-879-91 CAPACITOR 0.01µF 10% 250V
C528 1-115-349-51 CERAMIC 0.01µF 2KV
C529 1-136-060-00 FILM 0.047µF 5% 400V
C530 1-117-660-21 FILM 0.12µF 5% 250V
C531 1-119-858-11 FILM 0.068µF 5% 250V
C532
!
1-137-401-11 FILM 0.22µF 10% 100V
D
A
D
