REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
P780
— 40 —
C534
!
1-137-419-11 FILM 0.033µF 10% 100V
C535 1-130-495-00 FILM 0.1µF 5% 50V
C536 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C538 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C539
!
1-137-150-11 FILM 0.01µF 10% 100V
C540
!
1-136-203-11 FILM 10000pF 5% 630V
C541 1-126-963-11 ELECT 4.7µF 20% 50V
C542
!
1-126-964-11 ELECT 10µF 20% 50V
C543 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C544
!
1-137-370-11 FILM 0.01µF 5% 50V
C545 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C546 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C547 1-107-902-11 ELECT 1µF 20% 50V
C548 1-130-471-00 FILM 0.001µF 5% 50V
C549 1-137-375-11 FILM 0.068µF 5% 50V
C550 1-126-933-11 ELECT 100µF 20% 16V
C551 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C552 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C553
!
1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C554
!
1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C555
!
1-130-495-00 FILM 0.1µF 5% 50V
C556
!
1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C557 1-107-907-11 ELECT 22µF 20% 50V
C558
!
1-126-960-11 ELECT 1µF 20% 50V
C559 1-137-368-11 FILM 0.0047µF 5% 50V
C560 1-119-859-71 FILM 0.36µF 5% 250V
C561
!
1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C562 1-128-526-11 ELECT 100µF 20% 16V
C563 1-163-005-11 CERAMIC CHIP 470pF 10% 50V
C564 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C566 1-128-551-11 ELECT 22µF 20% 25V
C568 1-136-060-00 FILM 0.047µF 5% 400V
C569 1-130-495-00 FILM 0.1µF 5% 50V
C570 1-128-526-11 ELECT 100µF 20% 25V
C572 1-107-651-11 ELECT 4.7µF 20% 250V
C573 1-107-651-11 ELECT 4.7µF 20% 250V
C574 1-117-879-91 CAPACITOR 0.01µF 10% 250V
C575 1-110-641-51 ELECT 33µF 20% 200V
C576 1-163-243-11 CERAMIC CHIP 47pF 5% 50V
C577 1-115-349-51 CERAMIC 0.01µF 2KV
C578 1-107-974-11 CERAMIC 47pF 5% 2KV
C579 1-109-879-11 CERAMIC 22pF 5% 2KV
C580 1-137-370-11 FILM 0.01µF 5% 50V
C582 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C583 1-130-495-00 FILM 0.1µF 5% 50V
C601 1-104-664-11 ELECT 47µF 20% 10V
C602 1-162-117-00 CERAMIC 100pF 10% 500V
C603 1-126-942-61 ELECT 1000µF 20% 25V
C604
!
1-104-708-11 FILM 0.47µF 20% 250V
C605
!
1-104-708-11 FILM 0.47µF 20% 250V
C606 1-113-894-11 CERAMIC 100pF 10% 250V
C608 1-104-653-11 ELECT 220µF 20% 16V
C610 1-107-852-11 ELECT(BLOCK) 330µF 20% 400V
C611 1-163-007-11 CERAMIC CHIP 680pF 10% 50V
C612
!
1-119-858-11 FILM 0.068µF 5% 250V
C613
!
1-162-115-00 CERAMIC 330pF 10% 2KV
C614 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C615 1-163-037-11 CERAMIC CHIP 0.022µF 10% 50V
C616 1-107-907-11 ELECT 22µF 20% 25V
C617 1-107-907-11 ELECT 22µF 20% 25V
C618 1-130-495-00 FILM 0.1µF 5% 50V
C619 1-164-161-11 CERAMIC CHIP 0.0022µF 10% 50V
C620 1-162-117-00 CERAMIC 100pF 10% 500V
C621 1-104-712-11 ELECT 47µF 0 200V
C622 1-107-933-11 ELECT 100µF 20% 100V
C623 1-104-666-11 ELECT 220µF 20% 25V
C624 1-107-885-11 ELECT 3300µF 20% 16V
C625 1-126-768-11 ELECT 2200µF 20% 16V
C626 1-104-653-11 ELECT 220µF 20% 16V
C627 1-126-934-11 ELECT 220µF 20% 10V
C628 1-128-526-11 ELECT 100µF 20% 25V
C630 1-126-935-11 ELECT 470µF 20% 16V
C631 1-126-935-11 ELECT 470µF 20% 16V
C632 1-111-070-51 ELECT 0.0022F 20% 25V
C633 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C634 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C636 1-131-601-21 FILM 0.047µF 5% 250V
C637 1-107-888-11 ELECT 47µF 20% 25V
C638 1-113-894-11 CERAMIC 100pF 10% 250V
C640 1-113-912-11 CERAMIC 0.0047µF 20% 250V
C641 1-126-933-11 ELECT 100µF 20% 16V
C643 1-113-912-11 CERAMIC 0.0047µF 20% 250V
C647 1-102-228-00 CERAMIC 470pF 10% 500V
C650 1-163-019-00 CERAMIC CHIP 0.0068µF 10% 50V
C660
!
1-113-912-11 CERAMIC 0.0047µF 20% 250V
C661 1-117-699-11 CERAMIC 0.001µF 20% 250V
C701 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C702 1-126-963-11 ELECT 4.7µF 20% 50V
C703 1-136-169-00 FILM 0.22µF 5% 50V
C704 1-163-259-91 CERAMIC CHIP 220pF 5% 50V
C705 1-130-495-00 FILM 0.1µF 5% 50V
C706 1-163-113-00 CERAMIC CHIP 68pF 5% 50V
C707 1-163-113-00 CERAMIC CHIP 68pF 5% 50V
C708 1-130-495-00 FILM 0.1µF 5% 50V
C709 1-126-941-11 ELECT 470µF 20% 25V
C710 1-126-941-11 ELECT 470µF 20% 25V
C711 1-130-495-00 FILM 0.1µF 5% 50V
C712 1-130-495-00 FILM 0.1µF 5% 50V
C713 1-126-927-11 ELECT 2200µF 20% 10V
C714 1-163-131-00 CERAMIC CHIP 390pF 5% 50V
C715 1-126-935-11 ELECT 470µF 20% 16V
C716 1-163-989-11 CERAMIC CHIP 0.033µF 10% 25V
C718 1-163-989-11 CERAMIC CHIP 0.033µF 10% 25V
C723 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C725 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C729 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C733 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C901 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C902 1-126-935-11 ELECT 470µF 20% 16V
C903 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
