REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
P780
— 41 —
C905 1-137-375-11 FILM 0.068µF 5% 50V
C906 1-136-177-00 FILM 1µF 5% 50V
C908 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C909 1-126-926-11 ELECT 1000µF 20% 10V
C910 1-130-495-00 FILM 0.1µF 5% 50V
C911 1-137-370-11 FILM 0.01µF 5% 50V
C912 1-126-933-11 ELECT 100µF 20% 16V
C913 1-130-495-00 FILM 0.1µF 5% 50V
C914 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C915 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C916 1-126-965-11 ELECT 22µF 20% 50V
C917 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C918 1-126-964-11 ELECT 10µF 20% 50V
C920 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C921 1-126-935-11 ELECT 470µF 20% 16V
C922 1-109-889-11 ELECT 1µF 20% 50V
C923 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C924 1-126-965-11 ELECT 22µF 20% 50V
C925 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C926 1-126-935-11 ELECT 470µF 20% 16V
C927 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C928 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C929 1-163-009-11 CERAMIC CHIP 0.001µF 10% 50V
C930 1-137-370-11 FILM 0.01µF 5% 50V
C931 1-163-133-00 CERAMIC CHIP 470pF 5% 50V
C935 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C936 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C937 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C938 1-126-934-11 ELECT 220µF 20% 16V
CONNECTOR
CN501 * 1-580-798-11 CONNECTOR PIN (DY) 6P
CN502 * 1-564-512-11 PLUG, CONNECTOR 9P
CN512 1-695-915-11 TAB (CONTACT)
CN513 1-695-915-11 TAB (CONTACT)
CN600
!
1-251-644-11 INLET, AC 3P (WITH NOISE FILTER)
CN601 * 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN602 * 1-506-371-00 PIN, CONNECTOR 2P
CN604 1-695-915-11 TAB (CONTACT)
CN701 * 1-564-513-11 PLUG, CONNECTOR 10P
CN901 * 1-508-879-11 BASE POST
CN902 * 1-564-513-11 PLUG, CONNECTOR 10P
CN903 * 1-564-511-11 PLUG, CONNECTOR 8P
DIODE
D401 8-719-052-90 DIODE D1NL40-TA2
D402 8-719-921-40 DIODE MTZJ-4.7C
D403 8-719-988-61 DIODE 1SS355TE-17
D404 8-719-058-24 DIODE RB501V-40TE-17
D501 8-719-110-31 DIODE RD12ESB2
D502 8-719-981-00 DIODE ERC81-004
D504 8-719-110-49 DIODE RD18ESB2
D505 8-719-941-74 DIODE ERB91-02
D506 8-719-075-18 DIODE FMQ-G2FS
D507 8-719-109-85 DIODE RD5.1ESB2
D509 8-719-110-17 DIODE RD10ESB2
D510 8-719-018-82 DIODE RGP02-20EL-6394
D511 8-719-109-89 DIODE RD5.6ESB2
D512 8-719-991-33 DIODE 1SS133T-77
D513 8-719-052-90 DIODE D1NL40-TA2
D514 8-719-970-83 DIODE HSS82
D515
!
8-719-018-82 DIODE RGP02-20EL-6394
D516 8-719-052-86 DIODE D2L40-TA
D517
!
8-759-157-40 DIODE HZT33-02TE
D518 8-719-110-17 DIODE RD10ESB2
D519 8-719-991-33 DIODE 1SS133T-77
D520 8-719-018-82 DIODE RGP02-20EL-6394
D521 8-719-028-72 DIODE RGP02-17EL-6433
D522 8-719-991-33 DIODE 1SS133T-77
D523 8-719-991-33 DIODE 1SS133T-77
D524 8-719-051-85 DIODE HSS83TD
D525 8-719-051-85 DIODE HSS83TD
D527 8-719-109-85 DIODE RD5.1ESB2
D529 8-719-110-49 DIODE RD18ESB2
D601
!
8-719-510-53 DIODE D4SB60L
D602
!
8-719-991-33 DIODE 1SS133T-77
D603 8-719-991-33 DIODE 1SS133T-77
D604 8-719-991-33 DIODE 1SS133T-77
D605 8-719-110-31 DIODE RD12ESB2
D606
!
8-719-053-19 DIODE UF4007G23
D607 8-719-053-19 DIODE UF4007G23
D608 8-719-110-49 DIODE RD18ESB2
D609
!
8-719-991-33 DIODE 1SS133T-77
D610 8-719-109-81 DIODE RD4.7ESB2
D611 8-719-067-68 DIODE FMC-26UA
D612 8-719-053-19 DIODE UF4007G23
D613 8-719-076-20 DIODE BT149G-412-OT359
D614 8-719-032-12 DIODE D1NS6
D615 8-719-979-58 DIODE EGP10D
D616 8-719-979-58 DIODE EGP10D
D617 8-719-947-06 DIODE RGP10JPKG23
D618 8-719-058-38 DIODE FMN-G12S
D619 8-719-058-38 DIODE FMN-G12S
D620 8-719-300-76 DIODE RH-1A
D621 8-719-991-33 DIODE 1SS133T-77
D622 8-719-058-38 DIODE FMN-G12S
D704 8-719-991-33 DIODE 1SS133T-77
D901 8-719-073-01 DIODE MA111-(K8).S0
D902 8-719-047-98 DIODE HZU5.6B2TRF
D903 8-719-050-84 DIODE RB441Q-40T-77
D904 8-719-047-98 DIODE HZU5.6B2TRF
D905 8-719-991-33 DIODE 1SS133T-77
D906 8-719-988-61 DIODE 1SS355TE-17
D907 8-719-988-61 DIODE 1SS355TE-17
D908 8-719-988-61 DIODE 1SS355TE-17
D909 8-719-047-98 DIODE HZU5.6B2TRF
D910 8-719-047-98 DIODE HZU5.6B2TRF
D
