Dell P780 - 17" CRT Display User Manual

REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifies per un trame
et une marque
!
sont critiques pour la
securite. Ne les remplacer que par une
piece portant le numero specifie.
The components identified by
shading and mark
!
are critical
for safety. Replace only with
part number specified.
P780
— 42 —
D911 8-719-988-61 DIODE 1SS355TE-17
D912 8-719-075-53 DIODE SML16751WN
D913 8-719-988-61 DIODE 1SS355TE-17
D914 8-719-988-61 DIODE 1SS355TE-17
D915 8-719-988-61 DIODE 1SS355TE-17
D916 8-719-988-61 DIODE 1SS355TE-17
D917 8-719-988-61 DIODE 1SS355TE-17
D918 8-719-047-98 DIODE HZU5.6B2TRF
D919 8-719-988-61 DIODE 1SS355TE-17
D920 8-719-058-24 DIODE RB501V-40TE-17
D921 8-719-988-61 DIODE 1SS355TE-17
D924 8-719-988-61 DIODE 1SS355TE-17
D925 8-719-988-61 DIODE 1SS355TE-17
D926 8-719-988-61 DIODE 1SS355TE-17
D927 8-719-988-61 DIODE 1SS355TE-17
D928 8-719-047-98 DIODE HZU5.6B2TRF
D929 8-719-047-98 DIODE HZU5.6B2TRF
D930 8-719-047-98 DIODE HZU5.6B2TRF
D931 8-719-109-89 DIODE RD5.6ESB2
D932 8-719-109-89 DIODE RD5.6ESB2
D933 8-719-109-89 DIODE RD5.6ESB2
D934 8-719-047-98 DIODE HZU5.6B2TRF
D935 8-719-109-85 DIODE RD5.1ESB2
D936 8-719-109-89 DIODE RD5.6ESB2
D937 8-719-109-89 DIODE RD5.6ESB2
FUSE
F601
!
1-576-231-11 FUSE (H.B.C.) 4A/250V
FERRITE BEAD
FB502 1-412-473-51 INDUCTOR 0µH
FB504 1-412-911-11 FERRITE 0µH
FB506 1-412-911-11 FERRITE 0µH
FB904 1-543-961-22 FERRITE 0µH
IC
IC401 8-759-339-59 IC TDA8177
IC501
!
8-759-570-29 IC UPC6757CS
IC502 8-759-803-42 IC LA6500-FA
IC503 8-759-803-42 IC LA6500-FA
IC601
!
8-759-594-75 IC TEA1504/N2
IC602 8-759-592-79 IC BA00AST-V5
IC603
!
8-749-016-35 IC TLP621D4-Y-LF2T
IC604 8-759-586-17 IC TL1431CZ-AP
IC605 8-759-637-83 IC PQ12RD08S
IC607
!
8-759-450-47 IC BA05T
IC608 8-759-231-53 IC TA7805S
IC701 8-759-595-52 IC CXA8070AP
IC702 8-749-015-00 IC STK391-110
IC703 8-759-822-38 IC LA6510
IC901
!
8-759-640-86 IC CXD9529S-LHX
IC902 8-759-594-40 IC CXA8071CP
IC904 8-759-352-91 IC PST9143NL
IC905 8-759-527-76 IC M24C08-MN6T
CHIP CONDUCTOR
JR001 1-216-296-91 SHORT
JR003 1-216-295-91 SHORT
JR004 1-216-295-91 SHORT
JR006 1-216-295-91 SHORT
JR007 1-216-295-91 SHORT
JR008 1-216-296-91 SHORT
JR009 1-216-295-91 SHORT
JR010 1-216-296-91 SHORT
JR011 1-216-296-91 SHORT
JR012 1-216-295-91 SHORT
JR013 1-216-295-91 SHORT
JR014 1-216-296-91 SHORT
JR015 1-216-295-91 SHORT
JR016 1-216-295-91 SHORT
JR017 1-216-295-91 SHORT
JR018 1-216-295-91 SHORT
JR019 1-216-296-91 SHORT
JR020 1-216-296-91 SHORT
JR021 1-216-296-91 SHORT
JR022 1-216-295-91 SHORT
JR023 1-216-295-91 SHORT
JR024 1-216-296-91 SHORT
JR025 1-216-296-91 SHORT
JR027 1-216-296-91 SHORT
JR028 1-216-296-91 SHORT
JR029 1-216-295-91 SHORT
JR030 1-216-295-91 SHORT
JR032 1-216-296-91 SHORT
JR033 1-216-296-91 SHORT
JR034 1-216-295-91 SHORT
JR038 1-216-296-91 SHORT
JR604 1-216-295-91 SHORT
JR606 1-216-295-91 SHORT
COIL
L501 1-406-663-21 INDUCTOR 47µH
L502 1-406-663-21 INDUCTOR 47µH
L503 1-411-594-41 INDUCTOR 5mH
L505 1-412-552-11 INDUCTOR 2.2mH
L506 1-412-548-31 INDUCTOR 820µH
L507 1-414-856-11 INDUCTOR 10µH
L508 1-419-198-21 COIL, HORIZONTAL LINEARITY
L509 1-419-198-21 COIL, HORIZONTAL LINEARITY
L510 1-416-367-11 COIL, HORIZONTAL CENTER
L511 1-414-187-11 INDUCTOR 47µH
L513 1-414-856-11 INDUCTOR 10µH
L602 1-412-529-11 INDUCTOR 22µH
D
