Component Secured to Screw type Quantity Screw image

Touchpad bracket Palm-rest and keyboard

assembly

M2x3 3

Touchpad Palm-rest and keyboard

assembly

M2x2 Big Head 4

Display assembly Palm-rest and keyboard

assembly

M2.5x5 6

14 Screw list
