Removing the base cover
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Remove the six screws (M2x7) that secure the base cover to the palm-rest and keyboard assembly.
2 Loosen the three captive screws that secure the base cover to the palm-rest and keyboard assembly.
3 Using your ngertips, pry the base cover o the palm-rest and keyboard assembly from the top left corner.
4 Lift the base cover o the palm-rest and keyboard assembly.
6
Removing the base cover 15
