Removing the battery
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
Remove the base cover.
Procedure
1 Peel o the tape that secures the battery cable to the battery.
2 Peel the tape that secures the battery cable to the battery-cable connector.
3 Disconnect the battery cable from the system board.
4 Remove the two screws (M2x3) that secure the battery to the palm-rest and keyboard assembly.
5 Lift the battery o the palm-rest and keyboard assembly.
8
Removing the battery 19
