Replacing the speakers
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working inside
your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Using the alignment posts, align and place the speakers on the palm-rest and keyboard assembly.
NOTE: Replace the rubber grommets if they are pushed up while replacing the speakers.
2 Route the speaker cable through the routing guides on the palm-rest and keyboard assembly.
3 Connect the speaker cable to the system board.
Post-requisites
Replace the base cover.
23
42 Replacing the speakers
