NOTE: This step is for the system board that supports the 10
th
Generation Intel Core i3 processor.
8. Remove the heat sink (discrete graphics).
NOTE: This step is only applicable for the system board that ships with the following processors:
● Intel Celeron
● Intel Pentium Gold
● 11
th
Generation Intel Core i3/i5/i7
9. Remove the wireless card.
10. Remove the display assembly.
About this task
NOTE: The following procedure only applies to computers shipped with a Realtek ALC3204 audio controller.
The following images indicate the connectors on the system board.
NOTE: This system board supports the 10
th
Generation Intel Core i3 processor.
NOTE: This system board supports the following processors:
● Intel Celeron
● Intel Pentium Gold
● 11
th
Generation Intel Core i3/i5/i7
58 Removing and installing components
