1. Power-adapter port cable
2. Speaker cable
3. Keyboard cable
4. Keyboard-backlight cable
5. Touchpad cable
6. Battery cable
7. Hard-drive cable
8. I/O-board cable
9. Fingerprint-reader cable
10. Power-button cable
The following images indicate the location of the system board and provide a visual representation of the removal procedure.
NOTE: This system board supports the 10
th
Generation Intel Core i3 processor.
