PowerConnect 8024F connections with the PS6010 or PS6510:
Switch 1
Port
To
Switch 2
Port
To
1 Server 1, port 1
1 Server 1, port 2
2 Server 2, port 1 2 Server 2, port 2
3 Server 3, port 1
3 Server 3, port 2
4 Server 4, port 1
4 Server 4, port 2
Array 3
15 Controller 0, port 0
15 Controller 0, port 1
16 Controller 1, port 1 16 Controller 1, port 0
Array 2
17 Controller 0, port 0
17 Controller 0, port 1
18 Controller 1, port 1 18 Controller 1, port 0
Array 1
19 Controller 0, port 0
19 Controller 0, port 1
20 Controller 1, port 1 20 Controller 1, port 0
