Installing System Components 115
Figure 3-17. Installing or Removing an iDRAC6 Express Card
7
If applicable, replace the expansion card. See "Installing an Expansion
Card" on page 94.
8
Close the system. See "Closing the System" on page 79.
9
Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
1 iDRAC6 Express card 2 iDRAC6 Express card connector
3 retention standoff tab
R310HOM.book Page 115 Thursday, March 4, 2010 1:03 AM
