Installing System Components 139
Figure 3-26. Power Distribution Board
1 screws (2) 2 power supply cables (2)
3 power-distribution board 4 standoffs (2)
5 fan module cable connectors (2) 6 fan module power cables (2)
4
1
2
5
3
6
