Table 15. Dimensions of the Dell PowerEdge R730 system
Xa Xb Y Za (with
bezel)
Za (without
bezel)
Zb Zc
482.4 mm 444.0 mm 87.3 mm 32.0 mm 18.0 mm 684.0 mm 723.0 mm
Chassis weight
This section describes the weight of the system.
Table 16. Chassis weight
System Maximum weight (with all hard drives/SSDs)
PowerEdge R730
● 31.5 kg (69.45 lb) (3.5-inch hard drive systems)
● 31.4 kg (69.23 lb) (2.5-inch hard drive systems)
Processor specifications
The PowerEdge R730 system supports up to two Intel Xeon E5-2600 v3 or Intel Xeon E5-2600 v4 product family processors.
PSU specifications
The PowerEdge R730 system supports up to two AC or DC redundant power supply units (PSUs).
Table 17. PSU specifications
PSU Class Heat dissipation
(maximum)
Frequency Voltage
495 W AC Platinum 1908 BTU/hr 50/60 Hz 100–240 V AC, autoranging
750 W AC Platinum 2891 BTU/hr 50/60 Hz 100–240 V AC, autoranging
Titanium 2843 BTU/hr 50/60 Hz 200–240 V AC, autoranging
1100 W AC Platinum 4100 BTU/hr 50/60 Hz 100–240 V AC, autoranging
750 W DC (for China
only)
Platinum 2902 BTU/hr 100–240 V AC and 240 V DC
1100 W DC N/A 4416 BTU/hr N/A –(48–60) V DC
NOTE: Heat dissipation is calculated using the PSU wattage rating.
NOTE: This system is also designed to connect to the IT power systems with a phase to phase voltage not exceeding 230
V.
System battery specifications
The PowerEdge R730 system supports CR 2032 3.0-V lithium coin cell system battery.
Expansion bus specifications
The PowerEdge R730 system supports PCI express (PCIe) generation 3 expansion cards, which need to be installed on the
system board using expansion card risers. This system supports three types of expansion card risers. The following table
provides the expansion card riser specifications:
28
Technical specifications
