19 PowerEdge FX2 – FN I/O Module – VLT Deployment Guide | Version 2.2
FN2210S IOA A1 (Top)
Internal Ports
5 6
3
7
4
8
2
FN2210S IOA A2 (Bottom)
Internal Ports
1b
3a 3b
1c 1d
3c 3d
5 6
3
7
4
8
21
1
1a
Quarter-height slots with dual-port CNAs
Half-height slots with dual-port CNAs
Slot
IOA A1 port
numbers
(top)
IOA A2 port
numbers
(bottom)
1a
1
1
1b
2
2
1c
3
3
1d
4
4
3a
5
5
3b
6
6
3c
7
7
3d
8
8
