Dell PowerEdge R310 Technical Guide 57
12 I/O Slots
12.1 Overview
Table 19. PCIe Slot Specification
Slot
Connector
Routing
lanes
Technology Silkscreen Height Length
Slot1 X16 X8 PCIe 2.0 (5GT/s) SLOT1 PCIE_G2_x8
Full height
Half length
Slot2 X8 X8 PCIe 2.0 (5GT/s) SLOT2 PCIE_G2_x8
Full height
Half length
12.2 Quantities and Priorities
Table 20. I/O Slots Quantities and Priorities
Category Card Priority Description Width
Maximum
Cards
Slot
Priority
Internal
Controllers
100 PERC S300 Modular x4 Gen1 1 Slot 3
200 SAS 6/iR Modular x4 Gen1 1 Slot 3
300 PERC H700 Adapter x8 Gen2 1 Slot 2
300 PERC H700 Adapter NV RAM x8 Gen2 1 Slot 2
400 PERC H200 Adapter x8 Gen2 1 Slot 2
External
Controllers
500
PERC H800 512MB Adapter
x8 Gen2 2 Slot 1, 2
500
PERC H800 512MB Adapter NV
RAM
x8 Gen2 2 Slot 1, 2
600
6Gbps SAS HBA
x8 Gen2 2 Slot 1, 2
FC HBAs
800 QLE2562 FC8 Dual Channel HBA x8 Gen1 2 Slot 1, 2
900 LPe12002 FC8 Dual Channel HBA x8 Gen1 2 Slot 1, 2
1000 QLE2560 FC8 Single Channel HBA x8 Gen1 2 Slot 1, 2
1100
LPe12000 FC8 Single Channel
HBA
x8 Gen1 2 Slot 1, 2
NICs
1200
Intel Gigabit ET Quad Port Server
Adapter
x4 Gen2 2 Slot 1, 2
1300
Intel Gigabit ET Dual Port Server
Adapter
x4 Gen2 2 Slot 1, 2
1400
Broadcom NetExtreme II 5709
Dual-Port Gb Ethernet TOE
Server Adapter
x4 Gen1 2 Slot 1, 2
1500
Broadcom NetExtreme II 5709
Dual-Port Gb Ethernet TOE/iSCSI
Offload Server Adapter
x4 Gen1 2 Slot 1, 2
