PowerEdge R510 Technical Guide 29
4.10 Cabling
Table 10. Cabling Information
Chassis
Controller
Note
PowerEdge
R510-4
No Add-in RAID controller C0, C1
S100 C2A, C2B, C3, C4, C5
S300 Include data and LED
SAS 6/iR Include data and LED
PERC 6/i
Include data and LED
Battery cable
PERC H200 Include data and LED
PERC H700
Include data and LED
Battery cable
PowerEdge
R510-8
S300 Include data and LED
SAS 6/iR
Include data and LED
PERC 6/i
Include data and LED
Battery cable
PERC H200 Include data and LED
PERC H700
Include data and LED
Battery cable
For detailed cable installation, please refer to the Hardware Owner’s Manual.
4.11 Security
4.11.1 Bezel Lock
The bezel lock located on front of the bezel provides security for the system by preventing access to hard
drives, optical drives, and the power button.
4.11.2 Hard Drive Security
Hard drives are only accessible by unlocking and opening the bezel.
