20 About Your System
4 PCIe slot 4 PCIe x8-link Gen 2 expansion slot (full-
height, 24.13-cm [9.5-in] length)
5 power supply 1 (PS1) 870-W or 570-W power supply
6 power supply 2 (PS2) 870-W or 570-W power supply
7 system identification
button
The identification buttons on the front
and back panels can be used to locate a
particular system within a rack. When
one of these buttons is pushed, the
LCD panel on the front and the system
status indicator on the back flash blue
until one of the buttons is pushed
again.
8 system status indicator Provides a power on indicator for the
back of the system
9 system status indicator
connector
Connector for attaching a system
indicator extension cable that is used
on a cable management arm
10 Ethernet connectors
(4)
Integrated 10/100/1000 NIC connectors
11 USB connectors (2) Connects USB devices to the system.
The ports are USB 2.0-complaint
12 video connector Connects a VGA display to the system
13 serial connector Connects a serial device to the system
14 iDRAC6 Enterprise
port (optional)
Dedicated management port for the
optional iDRAC6 Enterprise card
15 VFlash media slot
(optional)
Connects an external SD memory card
for the optional iDRAC6 Enterprise
card
Item Indicator, Button, or
Connector
Icon Description

Dell POWEREDGE R710 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF7
Processor cache	8 MB
Processor cores	4
Processor model	E5530
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processing Die size	263 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	146 GB
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-ROM
Total storage capacity	292 GB
Maximum storage capacity	6 TB
Internal memory	12 GB
Memory clock speed	1066 MHz
Memory layout (slots x size)	6 x 2 GB
Graphics card	G200
Dimensions (WxDxH)	443.1 x 680.7 x 86.4 mm
Non-operating relative humidity (non-condensing)	5 - 95 %
PS/2 ports quantity	0
USB 2.0 ports quantity	5
Power supply	570 W
Power requirements	90 - 264V
Compatible operating systems	Windows Server, Standart Business Server, Novell SUSE Linux, Red Hat Linux Enterprise
Chassis type	Rack (2U)
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Networking features	Gigabit Ethernet
Processor ARK ID	37103
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	680.7 mm
Width	443.1 mm
Height	86.4 mm
Weight	26100 g
