92 Installing System Components
Figure 3-18. Replacing the System Battery
5 To install the new system battery, hold the battery with the "+" facing up,
and aligned to the metal tab on the socket. Press the battery straight down
into the socket until it snaps into place.
6 Close the system. See "Closing the System" on page 58.
7 Enter the System Setup program to confirm that the battery is operating
properly. See "Using the System Setup Program and UEFI Boot Manager"
on page 35.
8 Enter the correct time and date in the System Setup program's Time and
Date fields.
9 Exit the System Setup program.
1 positive side of battery connector 2 system battery
3 negative side of battery connector
2
3
1
