Back-Panel Features And Indicators
Figure 6. Back-Panel Features and Indicators
Item Indicator, Button, or
Connector
Icon Description
1 PCIe expansion card slots
(4) (processor 1)
Allows you to connect up to two PCI Express expansion
cards and two PERC cards.
2, 3 Ethernet connectors
Two integrated 10/100/1000 Mbps NIC connectors.
17
