PowerEdge T710 Technical Guide 16
Back View Figure 4.
See the Back-Panel Features and Indicators section in the About Your System chapter of the
PowerEdge T710 Hardware Owner’s Manual on Support.Dell.com for more information.
4.6 Power Supply Indicators
The PowerEdge T710 redundant power supplies have one status bi-color LED: green for AC power
present and amber for a fault as detailed in Table 3.
Power Supply Status Table 3.
LED
Power Supply Status
AC Power is not present
AC Power is present
Fault of any kind is detected
DC Power is applied to the system
↔
Redundant power supply mismatch
(when hot-plugged/swapped)
See the Power Indicator Codes section in the About Your System chapter of the PowerEdge T710
Hardware Owner’s Manual on Support.Dell.com for more information.
