Back and Left Side View
CAUTION: Do not block, push objects into, or allow dust to accumulate in the air
vents. Do not store your Dell computer in a low-airflow environment, such as a
closed briefcase, while it is running. Restricting the airflow can damage the
computer or cause a fire.The computer turns on the fan when the computer gets
hot. Fan noise is normal and does not indicate a problem with the fan or the
computer.
1 RJ-11 port 2 RJ-45 network port
3 power, HDD indicators 4 multimode DisplayPort
5 AC adapter 6 security cable slot
7 VGA 8 eSATA/PowerShare™ USB
port
9 PowerShare™ USB port 10 SmartCard Reader
