Table 38. Qualcomm Snapdragon SDX12 Global LTE-Advanced (DW5825e) specifications(continued)
Description Value
Extended operating temperature -30°C to +75°C
Antenna connector
● WWAN Main Antenna x 1
● WWAN Diversity Antenna x 1
Qualcomm Snapdragon X62 Global 5G Modem (DW5932e)
The following table lists specifications of the Qualcomm Snapdragon X62 Global 5G Modem (DW5932e) WWAN module.
Table 39. Qualcomm Snapdragon X62 Global 5G Modem (DW5932e) specifications
Description Value
Form factor M.2 3042 Key-B
Host interface PCIe Gen3
Network standard
● NR FR1 (Sub6) FDD/TDD
● LTE FDD/TDD
● WCDMA/HSPA+
● GPS/GLONASS/Beidou/Galileo
Transfer rate
● 5G NR: DL 3.5 Gbps/UL 900 Mbps
● LTE: DL 1.6 Gbps (CAT19)/UL 211 Mbps (CAT18)
● UMTS: DL DC-HSPA+ Rel8:42 Mbps/UL 5.76 Mbps
Operating frequency bands
● NR (n1, n2, n3, n5, n7, n8, n12, n13, n14, 18, n20, n25, n26,
n
28, n30, n38, n40, n41, n48, n53, n66, n70, n71, n75, n76,
n77, n78, n79)
● LTE (B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18,
B
19, B20, B25, B26, B28, B29, B30, B32, B34, B38, B39,
B40, B41, B42, B43, B46, B48, B66, B71)
● WCDMA/HSPA+ (1, 2, 4, 5, 8)
Power supply DC 3.135 V to 3.63 V, Typical 3.3 V
SIM card Supported through external SIM-card slot
eSIM with Dual SIM (DSSA) Supported
NOTE:
The availability of eSIM functionality embedded on
the module is dependent on the region and specific carrier
requirements.
Antenna diversity Supported
Radio On/Off Supported
Wake on wireless Supported
Normal operating temperature -30°C to +70°C
Extended operating temperature -40°C to +85°C
Storage temperature -40°C to +85°C
Antenna connector
● WWAN Main Antenna x 1
● WWAN Diversity Antenna x 1
● 4x4 MIMO Antenna x 2
Engineering specifications 37
