Dell Precision 3580 Technical Guidebook

Left
1. Thunderbolt 4.0 port with Power Delivery and DisplayPort
Supports USB4, DisplayPort 1.4, Thunderbolt 4 and also enables you to connect to an external display using a display adapter.
Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4.
NOTE: You can connect a Dell Docking Station to the Thunderbolt 4 ports. For more information, search in the
Knowledge Base Resource at www.dell.com/support.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
NOTE: Thunderbolt 4 supports two 4K displays or one 8K display.
2. Thunderbolt 4.0 port with Power Delivery and DisplayPort
Supports USB4, DisplayPort 1.4, Thunderbolt 4 and also enables you to connect to an external display using a display adapter.
Provides data transfer rates of up to 40 Gbps for USB4 and Thunderbolt 4.
NOTE:
You can connect a Dell Docking Station to the Thunderbolt 4 ports. For more information, search in the
Knowledge Base Resource at www.dell.com/support.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
NOTE: Thunderbolt 4 supports two 4K displays or one 8K display.
3. Battery-status light
Indicates the battery-charge status.
Solid yellow—Battery charge is low.
Blinking yellow—Battery charge is critical.
4. Smart-card reader slot (optional)
6
Views of Precision 3580

Dell Precision 3580 Specifications

General

Processor	13th Gen Intel Core i5/i7/i9 or Xeon
Display	15.6-inch, FHD 1920 x 1080, 60 Hz, Anti-Glare, Non-Touch
Graphics	NVIDIA RTX A500
Memory	Up to 64GB DDR5
Storage	Up to 4TB PCIe NVMe SSD
Operating System	Windows 11 Pro
Ports	2 x Thunderbolt 4, 2 x USB 3.2 Gen 1
Wireless	Wi-Fi 6E, Bluetooth 5.2
Camera	1080p
Battery	4 Cell, 64 Wh
Weight	Starting at 1.79 kg (3.95 lbs)
