Power adapter
The following table lists the power adapter specifications of your Precision 5770.
Table 15. Power adapter specifications
Description Option one Option two
Type
90 W USB Type-C 130 W Type-C
Input voltage
100 VAC to 240 VAC 100 VAC to 240 VAC
Input frequency
50 to 60 Hz 50 to 60 Hz
Input current (maximum)
1.50 A 1.80 A
Output current (continuous)
● 20 V/4.5 A
● 15 V/3 A
● 9 V/3 A
● 5 V/3 A
● 20 V/6.5 A
● 5.0 V/1 A
Rated output voltage
● 20 VDC
● 15 VDC
● 9 VDC
● 5 VDC
● 20 VDC
● 5 VDC
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to 158°F) -40°C to 70°C (-40°F to 158°F)
CAUTION: Operating and storage temperature ranges may differ among components, so operating or storing
the device outside these ranges may impact the performance of specific components.
Battery
The following table lists the battery specifications of your Precision 5770.
Table 16. Battery specifications
Description Option one Option two
Battery type
3-cell, 56 WHr ExpressCharge 6-cell, 97 WHr ExpressCharge
Battery voltage
11.40 VDC 11.40 VDC
Battery weight (maximum)
0.27 kg (0.60 lb) 0.385 kg (0.85 lb)
Battery dimensions:
Height
8.45 mm (0.33 in.) 8.45 mm (0.33 in.)
Width
69.70 mm (2.74 in.) 69.70 mm (2.74 in.)
Depth
330.65 mm (13.02 in.) 330.65 mm (13.02 in.)
Temperature range:
16 Specifications of Precision 5770
