Table 25. Intel AX211 specifications (continued)
Antenna diversity Supported
Radio On/Off Supported
Roaming Support seamless roaming between access points
Wake on wireless Supported
Wireless display Native Miracast support by Windows
Wireless PAN standard
● Dual Mode Bluetooth 5.2
● BLE
Bluetooth data rates Up to 3 Mbps
Bluetooth operating frequency bands 2.4 GHz
Bluetooth profiles supported Support for Microsoft Inbox Bluetooth profiles in Windows
Bluetooth data encryption 128-bit encryption
Bluetooth output power Power class 1
Operating temperature 0°C to + 50°C (Full performance at shield temperatures up to
80°C)
Storage temperature -40°C to +70°C
Humidity Up to 90% RH non-condensing (at temperatures of 25° C to
35° C)
GPU—Integrated
Intel UHD Graphics
The following table lists the Intel UHD Graphics specifications.
Table 26. Intel UHD Graphics specifications
Bus type Integrated graphics
Memory type UMA
Graphics level i5/i7/i9: GT2 (UHD)
Estimated maximum power consumption (TDP) 12 W-28 W, included in the CPU power
Overlay planes Yes
Operating systems graphics/ video API support DirectX 12, OpenGL (4.5 from Intel CML POR)
Maximum vertical refresh rate Up to 120 Hz
NOTE: The refresh rate depends on the resolution.
External ports Thunderbolt 4
Multiple display support
Up to 4 displays via DisplayPort Multi-Streaming Technology
(MST)
22 Engineering specifications
