Dell Precision 7730 - Dell Wireless 5811 E M.2 Mobile Broadband Card

• Windows 8.1, 32/64 bits
• Microsoft WHQL certied for Windows 10, 32/64 bits
Client utility
• Windows 7, 32/64 bits
• Windows 8.1, 32/64 bits
• Microsoft WHQL certied for Windows 10, 32/64 bits
Radio On/O Supported Hardware and software on/o disables transmit and
receive to comply with aviation in-ight restrictions
LED output Supported Wireless LED on when WWAN/LTE radio enabled
SIM card format Format: Micro-SIM (3FF), Support voltage type: 1.8V and 3V
Roaming Roaming to supported bands comply with 3GPP standards
GNSS Supported both autonomous GNSS (GPS, GLONASS, BeiDou ,
Galileo) and assisted GNSS (A-GNSS) on frequency band L1
Humidity Up to 85% relative humidity for 48 hours, non-condensing
Temperature
• Operational : -30°C to +70°C Class A - 3GPP compliant
• Non-operational : -40°C to +85°C for 96 hours (from MIL-STD
202 method 108)
Wake On Wireless Supported WWAN/LTE module wake on wireless feature when
system platform implements control pins for waking the host side
Dell wireless 5811E M.2 mobile broadband card
Table 52. Wireless connectivity options
Connectivity option Region Carriers
Dell Wireless Qualcomm Snapdragon X7
LTE-A (DW5811e for EMEA/APJ/ROW)
APJ/EMEA/ROW (except China and
Indonesia)
• EMEA : Generic (no SIM)
• APJ : Generic (no SIM)
Dell Wireless Qualcomm Snapdragon X7
HSPA+ (DW5811e for China/Indonesia)
China and Indonesia Generic (no SIM)
Dell Wireless Qualcomm Snapdragon X7
LTE-A (DW5811e for DAO)
US and Canada
• US : AT&T, Verizon, Sprint
• Canada : Generic (no SIM)
NOTE:
• WWAN and HCA (Hardware Crypto Accelerator) cannot coexist
• SIM slot is not 100% tied, but tied to hinge up with WWAN antenna
• WWAN antenna must be selected at POS
• There as no WWAN and WLAN Customer Kits
