Left Side View
security cable slot — Letsyouattachacommerciallyavailableantitheftdevicetothecomputer.Formoreinformation,seeSecurity Cable Lock.
air vent — The computer uses fan(s) to create airflow through the vent(s), which prevents the computer from overheating.
USB connectors — Connect USB devices, such as a mouse, keyboard, or printer. You can also connect the optional floppy drive directly to a USB connector
using the optional floppy-drive cable.
optical drive — You can install devices such as a DVD drive or other optical drive in the optical drive bay. For more information, see Optical Drive.
optical-drive-tray eject button — Press this button to eject a CD or DVD from the optical drive. This button only works when the computer is turned on.
Right Side View
smart card slot — Supports one smart card. See Smart Cards.
hard drive — Stores software and data.
ExpressCard slot — Supports one ExpressCard, such as a modem or network adapter. The computer ships with a plastic blank installed in the slot. For more
information, see Using Cards.
IEEE 1394 connector — Connects devices supporting IEEE 1394 high-speed transfer rates, such as some digital video cameras.
CAUTION: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your computer in a low-airflow environment,
such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire.
