Feature Specification
• Nvidia Quadro K4100M, 4GB GDDR5 VRAM
• Nvidia Quadro K5100M, 8GB GDDR5 VRAM
Table 20. Audio
Feature Specification
Integrated dual-channel High-Definition audio
Table 21. Communication
Feature Specification
Network adapter network interface card capable of 10/100/1000 Mb/s
communication
Wireless
• internal wireless local area network (WLAN)
• internal wireless wide area network (WWAN)
• bluetooth wireless support
• WiGig support
• Bluetooth 4.0
Table 22. Expansion Bus
Feature Specification
Bus Type PCI 2.3, PCI Express 1.0 and 2.0, SATA 1.0A ,2.0 and 3.0, USB
2.0 and 3.0
Bus Width PCIe X16
BIOS Chip (NVRAM) 96 Mb (12 MB)
Table 23. Ports and Connectors
Feature Specification
Audio two connectors for line-out and line-in/microphone
Network Adapter one RJ45 connector
USB 2.0 four
USB 3.0 four
eSATA\USB 2.0 one
Video 15-pin VGA connector, 19-pin HDMI connector, 20-pin
DisplayPort connector
Memory card reader SD 4.0
Docking port one
Micro Subscriber Identity Module
(Micro SIM) port
one
73
