Dell Precision™ T3500 Service Manual--LED Codes
file:///C|/Biz%20Client/2015/NewBalance/Info%20Dev%20Root/New%20Balance/SM/A00/EN/Source/diags.htm[5/15/2015 11:40:58 AM]
5. Type 1 to start the menu and press <Enter> to proceed.
6. Select Run the 32 Bit Dell Diagnostics from the numbered list. If multiple versions are listed, select the version
appropriate for your computer.
7. When the Dell Diagnostics Main Menu appears, select the test you want to run.
Dell Diagnostics Main Menu
1. After the Dell Diagnostics loads and the Main Menu screen appears, click the button for the option you want.
Option Function
Express
Test
Performs a quick test of devices. This test typically takes 10 to 20 minutes and requires no interaction on your
part. Run Express Test first to increase the possibility of tracing the problem quickly.
Extended
Test
Performs a thorough check of devices. This test typically takes 1 hour or more and requires you to answer
questions periodically.
Custom
Test
Tests a specific device. You can customize the tests you want to run.
Symptom
Tree
Lists the most common symptoms encountered and allows you to select a test based on the symptom of the
problem you are having.
2. If a problem is encountered during a test, a message appears with an error code and a description of the problem.
Write down the error code and problem description and follow the instructions on the screen.
3. If you run a test from the Custom Test or Symptom Tree option, click the applicable tab described in the following
table for more information.
Tab Function
Results Displays the results of the test and any error conditions encountered.
Errors Displays error conditions encountered, error codes, and the problem description.
Help Describes the test and may indicate requirements for running the test.
Configuration Displays your hardware configuration for the selected device.
The Dell Diagnostics obtains configuration information for all devices from system setup, memory, and
various internal tests, and it displays the information in the device list in the left pane of the screen. The
device list may not display the names of all the components installed on your computer or all devices
attached to your computer.
Parameters Allows you to customize the test by changing the test settings.
4. When the tests are completed, if you are running the Dell Diagnostics from the Drivers and Utilities disc, remove the
disc.
5. Close the test screen to return to the Main Menu screen. To exit the Dell Diagnostics and restart the computer, close
the Main Menu screen.
Power Button Light Codes
The power LED located in the power button on the front of the computer illuminates and blinks or remains solid to indicate
five different states:
No light—System is in the off state (S5, or mechanical (AC power not applied) OFF).
Solid Amber—System fault, but Power Supply is good—normal operating state (S0 ).
Blinking Amber—System fault error condition including Power Supply (only +5VSB working), Vreg failure, missing or
bad CPU.
Blinking Green—System is in power saving states S1, S3 or S4. (Blink rate is 1Hz). No fault/error condition.
Solid Green—System is fully functional and is in S0 (ON) state.

Dell Precision T3500 Specifications

General

Tcase	67.9 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	W3550
System bus rate	4.8 GT/s
Processor series	Intel Xeon 3500 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Bloomfield
Processing Die size	263 mm²
Processor frequency	3.06 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	130 W
Processor core voltage (AC)	1.225 V
Number of processors installed	1
CPU multiplier (bus/core ratio)	23
Memory types supported by processor	DDR3-SDRAM
Number of Processing Die Transistors	731 M
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	24 GB
Display	LCD
Graphics card	FirePro V5900
Dimensions (WxDxH)	172 x 468 x 447 mm
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card manufacturer	AMD
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® X58 Express
Memory slots	-
Internal memory	4 GB
Memory channels	Triple-channel
Memory clock speed	1333 MHz
Memory layout (slots x size)	2 x 2 GB
HDD speed	7200 RPM
HDD capacity	500 GB
HDD interface	SATA III
Optical drive type	DVD Super Multi DL
Maximum graphics card memory	2.048 GB
Display diagonal	22 \
Display number of colors	16.78 million colors
PS/2 ports quantity	2
USB 2.0 ports quantity	11
VGA (D-Sub) ports quantity	0
Chassis type	Tower
Product color	Black, Silver
Cable lock slot type	Kensington
Number of 3.5\" bays	3
Operating system installed	Windows XP Professional
Compatible operating systems	Windows 7
Power supply	525 W
Processor ARK ID	39720
Processor package size	42.5 x 45.0 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	468 mm
Width	172 mm
Height	447 mm
Weight	17700 g
